The Ruger 10/22 (Magnum, Standard or Compact) models differ greatly from the other Ruger auto-loading rifles. Typical of Ruger design, though, the process to remove the front sight of a Ruger 10/22 is relatively simple but will require some time.
Items you will need
Padded gun vise
Penetrating lubricant
Flathead screwdriver
Punch
Small wood mallet
Check that the rifle is completely unloaded. Remove the magazine, rack the bolt and check the chamber.
Mount the Ruger 10/22 in a padded gun vise. Grip the stock of the rifle about three-quarters of the way up the barrel between the rear and front sight.
Spray the front sight and the front sight retaining ring with penetrating lubricant. Let the rifle sit overnight to allow the lubricant to completely work its way into the sight assembly.
Remove the sight ring retention bolt using a flathead screwdriver. Turn the bolt counterclockwise until it is loose enough for you to remove it from the ring by hand.
Strike the sight on the side just above the retention collar, using a punch and a wooden mallet. Then strike it on the other side, and repeat until the sight collar loosens up and you can see that the whole assembly "rocks" when you strike it.
Use the punch and wooden mallet to drive the front sight off the barrel. Place the punch at the base of the sight (where the sight joins the collar, do not strike it at the collar) and hit it with the mallet. Use short, sharp steady blows until the entire assembly comes off the barrel.
Warnings
- Never work on a loaded weapon. A sudden impact to the body of the weapon can cause it to discharge.
Tips
- Don't change your sight the day before a big hunting trip or shooting match. Plan on making the change so you will have enough time to get used to your new sight.
References
- Instruction Manual for Ruger Model 10/22 Autoloading Rifles; Sturm, Ruger & Co.; 2005
Tips
- Don't change your sight the day before a big hunting trip or shooting match. Plan on making the change so you will have enough time to get used to your new sight.
Warnings
- Never work on a loaded weapon. A sudden impact to the body of the weapon can cause it to discharge.
