Coyotes have expanded their native range from being mostly a creature of the Western plains and deserts to establish populations in each of the contiguous states in the USA. Coyotes have also adapted to living in close proximity to humans in rural, suburban and even urban settings. As a result, interest in trapping coyotes as a recreational pursuit as well as to control their population is increasing. A cable restraint trap is effective, inexpensive and easy to construct.
Items you will need
Aircraft cable, 1/8 inch
Hex nuts, 1/4 inch
Flat washer, 3/8 inch
Hammer
Anvil
Vise
Drill bit, 5/32 inch
Wire cutters
Making the Restraint
Cut the 1/8 inch aircraft cable with wire cutters to a 48 inch length.
Drill a 5/32-inch hole at the 12 o'clock and 6 o'clock positions on the flat washer half way from the center hole of the washer to the outer edge of the washer.
Pinch the washer in a bench vise so half the washer extends above the jaws of the vise and half the washer is gripped by the vise. One of the drilled holes should be at the top, the other at the bottom.
Thread the aircraft cable through a 1/4-inch nut, then back through the nut going the opposite direction forming a loop in the cable. Tighten the loop until it's 3/4 inch in diameter.
Lay the nut with the cable running through it on edge on an anvil. Hammer the edge of the nut pinching it tightly across the strands of the cable, securing the loop.
Thread the end of the cable opposite the end with the 3/4-inch loop through one of the holes drilled in the washer from the outside of the bend. Pull 18 inches of the cable through the washer hole. Now thread the end of the cable through the other hole on the washer, this one from the inside of the bend to the outside.
Push the unlooped end of the cable through a 1/4-inch nut.
Place the nut on edge on an anvil with ½ inch of cable protruding through the center of the nut.
Hammer the edge of the nut until it flattens and grips tightly onto the strands of the cable.
